Chop Cutter BOON-360EV
Model pursuing the ultimate in productivity improvement!!
Features of Hera (BOON-360EV)
Maximum Speed 380 Slices/Min
Handles thin and thick slicing of frozen meat materials (-5℃ to -2℃) up to a maximum width of 360mm. High-speed slicing at maximum 380 slices per minute.
Easy Operation with Large Color LCD Touch Panel
The 5.7-inch LCD touch panel is easy to see and simple to operate. Anyone can easily set work parameters such as thickness settings and slice settings.
Labor-Saving with Air Chucking
The claw section features automatic air chucking, which saves labor and improves work efficiency.
Convenient Meat Head Positioning Function
After the meat is held by the claw section, the head positioning sensor automatically feeds it to the slice start point.
Other Features
- Good yield rate
- Emphasis on safety and security
Product Documentation
Main Unit Specifications
| Machine Dimensions | Width 1,855 × Depth 1,092 × Height 1,446mm |
|---|---|
| Machine Weight | 665kg |
| Power Supply | 3-phase 200V 50/60Hz 30A or more |
| Motor Capacity | For blade: 3.7kW × 1 unit For feeding: 1.5kW × 1 unit |
| Slicing Capacity | Maximum 380 slices/min |
| Slice Thickness | (0)-3.0mm 380 slices/min (0)-4.0mm 350 slices/min (0)-5.0mm 315 slices/min (0)-8.0mm 250 slices/min (0)-15.0mm 200 slices/min (0)-30.0mm 140 slices/min |
| Sliceable Dimensions | Width 360 × Height 200 × Length 650mm ※When using head positioning function: Length 550mm |
| Suitable Slicing Temperature | -5℃ to -2℃ ※Varies slightly depending on meat thickness, quality, and shape |
※Specifications may be changed without notice for product improvement.
